| Manufacturer | Gehl |
| Model | Rt250 |
| Type | Compact track loader |
| Lift Design | Radial |
| Years Made | 2013 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.3 HP | 55.4 kW |
| Lifting Capacity (35% Tipping) | 2500 lbs | 1134 kg |
| Lifting Capacity (50% Tipping) | 3570 lbs | 1620 kg |
| Operating Weight | 11595 lbs | 5259 kg |
| Tipping Load | 7143 lbs | 3240 kg |
| Lift Breakout Force | 4406 lbs | 1999 kg |
| Tilt Breakout Force | 6894 lbs | 3127 kg |
| Max. Travel Speed | 7.9 mph | 12.7 km |
| Ground Pressure | 4.7 psi | 32.4 kPa |
Cycle Time
| Raise Lift Arms | 4.6 sec. |
| Lower Lift Arms | 3.1 sec. |
| Bucket Rollback | 2.5 sec. |
| Bucket Dump | 3.4 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 24.9 GPM | 94.3 LPM |
| Relief Pressure | 3000 psi | 206.8 Bar |
| Optional High Flow | 37.4 GPM | 141.6 LPM |
| Hydraulic Capacity | 21.9 gal | 82.6 L |
Engine Specs
| Manufacturer | Deutz |
| Model | TD3.6 L4 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 |
| Rated Speed | 2300 RPM |
| Torque Power | 1600 RPM |
| Combustion | Common Rail |
| Compression Ratio | 17.2:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 74.3 HP | 55.4 kW |
| Net Power | 74.3 HP | 55.4 kW |
| Displacement | 221 cu in. | 3621 cc |
| Bore | 3.8 in. | 9.8 cm |
| Stroke | 4.7 in. | 12.0 cm |
| Peak Torque | 243 ft-lb | 329 N∙m |
| Coolant Capacity | 5.1 gal | 19.3 L |
| Engine Oil Capacity | 2.2 gal | 8.5 L |
| Fuel Tank Capacity | 24.0 gal | 90.8 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 83.1 in. | 211.1 cm |
| Bucket Hinge Pin | 128.0 in. | 325.1 cm |
| Width | 69.5 in. | 176.5 cm |
| Length | 166.0 in. | 421.6 cm |
| Dump Height | 91.7 in. | 232.9 cm |
| Dump Reach | 39.2 in. | 99.6 cm |
| Ground Clearance | 13.0 in. | 33.0 cm |
| Dump Angle | 41° |
| Rollback Angle | 33° |
| Departure Angle | 25° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Shoe Width | 17.7 in. | 45.0 cm |
| Track Length | 125.0 in. | 317.5 cm |
| Ground Contact Length | 61.5 in. | 156.2 cm |
